GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip

I'm Online Chat Now

GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip

China GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip supplier
GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip supplier GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip supplier

Large Image :  GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip

Product Details:

Place of Origin: China
Brand Name: GE Medical/Datex-Ohmeda
Certification: CE
Model Number: OXY - F4 - MC, OxyTip + OXY - W - UN

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: 10*7*3(CM)/pc
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union
Supply Ability: 1000pcs/day
Detailed Product Description
Material: TUP/PVC - Latex - Free Function: Dressings And Care For Material
Style: Clip, Softwrap Color: Grey, White And Blue
Connector: DB9pin Or 8pin Warranty: 12 Months
High Light:

reusable spo2 sensor

,

spo2 probe sensor

Detailed Product Description



Suitable for Model.No: GE Ohmeda TruSat™
pulse oximeter

GE Ohmeda Trusat OXY-F4-MC neonate wrap spo2 sensor



Connector guide: DB-9pin



OEM P/N: OXY-W4-MC.



Compatible Monitors: Datex-Ohmeda® TruSat®, TruSat® ED, TruSat® TD.





OEM:

OXY-F4-MC (Adult Clip)

OXY-W4-MC (Neonate Silicon Wrap)

OXY-E4-MC (Adult Ear Clip)



http://www.spo2-ecg.com



OEM P/N Part No. Description(Cable & Connector)
OXY-F4-MC GOJ0001C Adult finger clip, DB9pins,Male
  GOJ0002C Pediatric finger clip,DB9pins,Male
  GOJ0003C Adult silicone soft tip, DB9pins,Male
  GOJ0004C Pediatric silicone soft tip,DB9pins,Male
OXY-W4-MC GOJ0005C Neonate silicone Wrap, DB9pins,Male
OXY-E4-MC GOJ0006C Adult ear clip spo2 sensor ,DB9pins,Male
GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip


Compatible Model.No: GE-Ohmeda Medical System

Compatible Datex-Ohmeda OxyTip OXY - W- UN neonate SpO2 Sensor, 8pins, 3m

GE ohmeda OXY-SE-3 multi-site Y type with separate wrap Spo2 sensor

Datex Ohmeda oxytip+ OXY-E-UN Adult ear clip spo2 sensor



Compatible models: Ohmeda TruSat 3755, TruSat TD, series 37XX, 3800, 3900, 3900P, 4700, 5250, Cardiocap 5, S/5, AS/3 (N-XOSAT or o), CS/3 (M-OSAT).



OEM P/N Part No. Description(Cable & Connector)
OXY-F-UN GOJ0001B Adult finger clip, 8pins,Male, need extension cable
  GOJ0002B Pediatric finger clip,need extension cable
  GOJ0003B Adult silicone soft tip, need extension cable
  GOJ0004B Pediatric silicone soft tip,need extension cable
OXY - W- UN GOJ0005B Neonate silicone Wrap, need extension cable
oxytip+ OXY-E-UN GOJ0006B Adult ear clip spo2 sensor ,need extension cable
GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip




TECHNICAL PARAMETERS:

LEDS Red 660nm normal
Infrared 880 / 905 / 940nm normal
Test Range Oxygen Saturation(%SpO2) 0 % to 100 %
Pulse Rate(bpm) 30 to 245
Accuracy SpO2 ± 2%(90% -1 00 %)
±3%(70%-89 %)
unspecified(0-69 %)
Pulse Rate ±1 bpm(30 - 59bpm)
±2 bpm(60 - 149bmp)
±3 bpm(150 - 245bmp)
Storage and Transport Environment - 10°C~ + 40°C
Operating Temperature + 5°C~ + 40°C
Operating/Storage/Transportation humidity 0% - 80%
Hyperbaric pressure 86kPa - 106 kPa

Products more details
1. Adult finger clip type spo2 sensor
Such blood oxygen probe, sensor acquires signal on adult fingers, the hard plastic shell for fixed sensors is larger and fits adult measurement, the instruments of different brand its probe shell may be slightly different, different shell shape cannot influence the performance of product.
2. Pediatric finger clip type spo2 sensor
Such blood oxygen probes, sensors in children's fingers acquisition signal, the hard plastic shell used in fixed sensor is smaller and measurements are suitable for children.
3. Adult Soft Tip type spo2 sensor./soft rubber/soft silicone tip
Such blood oxygen probe, sensor covered on adult finger to collect signals, the soft gel coat used in fixed sensors is bigger, suitable for adults. Different brands of instruments and its probe coat may be slightly different, different shape of coat cannot influence the product performance.
4. Neonatal wrap spo2 sensor or"Y" type wrap spo2 sensor.
The type of blood oxygen sensor, the sensor wrapped in neonatal acquisition signals on his foot, fixed sensors used in soft gel coat is bind package type, suitable for newborns.



GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip



GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip GE Medical SPO2 Finger Sensor DB 9 pin / pulse oximeter probe Finger Clip And Softtip
